Titanium Hexagon Socket Button Head Screws ISO7380

Name: Titanium Hexagon socket button head screws
Materials: CP Titanium grade 2 and Alloy titanium grade 5, gr. 7, gr.9, gr.12, gr.23 etc
Head: Hexagon socket button head
Standard: ISO7380
Size: M3-M12
MOQ: 100pcs
Surface: Titanium bright surface or can do other colors: black, gold, blue, red, purple, rainbow color, etc.
Laser Marking: Marking content is determined by the customer
MTC: EN10204 3.1
Samples: we can free samples

Send Inquiry

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Products Description

Titanium Hexagon socket button head screws ISO7380 are fasteners with a hexagonal socket (also known as an Allen socket) and a rounded, low-profile button head. They are made of titanium and meet the International Organization for Standardization (ISO) 7380 specification, which sets standards for the dimensions and tolerances of this type of screw.

These screws are commonly used in applications where a low profile and a clean appearance are desired, such as in electronics, aerospace, and medical equipment. Titanium is a popular material for these screws due to its high strength-to-weight ratio, corrosion resistance, and biocompatibility (in medical applications).

The ISO 7380 specification sets standards for the dimensions, materials, and mechanical properties of these screws. This includes the head diameter, head height, thread pitch, and length. The specification also defines the testing and inspection procedures to ensure the screws meet the required standards.

Features of titanium hex socket button screws

1. High strength-to-weight ratio;

2. Corrosion resistance;

3. Biocompatibility;

4. Low profile and Easy installation;

5. Durable;

6. Lightweight;

7. Resistant to fatigue.

ISO7380 Hexagon socket button head screws

Main produce process1. Cutting the titanium bar: cutting titanium bars to make titanium bolts; 2. Machined the head of screws;3. Check size;4. Head matching and shank diameter lathing for next steps.5. Check the semifinished products;6. Thread rolling; 7. Final quality check;8 stock and delivery;

Products drawing

drawing of ISO7380

Products parameters

Name:	Titanium Hexagon socket button head screws ISO7380
Standard:	ISO7380
material:	Gr.2 and Grade 5 grade 9 grade 12 grade 23
Size:	From M3-M12
Color:	titanium nature bright color or your needed color
Laser mark:	we can laser mark as your required content
MOQ:	100PCS
MTC	EN10204 3.1
