N6 Nickel Plates

Name: Pure nickel plates
Material grade:N4 N5（N02201）N6 N7（N02201）N8 DN Thickness: 0.8-70.0mm
hot rolled or cold rolled surface: pickle or bright annealed

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Company profile

We have specialized in producing pure nickel and nickel alloy materials for over 20 years, including pure N6 Nickel plates, nickel strips, nickel foils, nickel sheets, nickel tubes, rods, etc. nickel plate material grades include N4 N5 N6 N7 N8 DN, Our pure N6 nickel plates and have nickel content greater than 99% or more. N6 is most commonly used among the various processed materials of pure nickel because it not only has good hot and cold processing performance, but also is resistant to alkali corrosion, and thus is used more in the environmental protection and chemical fields.

Nickel each grade Product chemical composition

Grade	Chemical elements	Content(%)
Grade	Chemical elements	Ni+Co	Cu	Si	Mn	C	Mg	S	P	Fe	Pb	Cr	Total impurities
N6	Max	99.5	-	-	-	-	-	-	-	-	-	-	-
N6	Min	-	0.10	0.10	0.05	0.10	0.10	0.005	0.002	0.10	0.002	-	0.5

nickel plate mechanical property

Grade	state	size(mm)	mechanical property(no more than)			Hardness
Grade	state	size(mm)	Rm/MPa	Rp0.2/MPa	A50(%)	HV	HRB
N6 N7(N02200) DN	M	≤1.5	380	100	35
	M	>1.5	380	100	40
	R	>4.0	380	135	30
	Y	>1.5	620	480	2	188-215	90-95
	Y	≤1.5	540	-	-
	Y2	>1.5	490	290	20	147-170	79-85

Products range

The nickel materials we produce include the following:

nickel bars

Nickel round bars: diameter 12-300mm, length 300-6000mm

Nickel billet tube and seamless pipe

Nickel billet tubes: outer diameter 70-200mm, wall thickness 6.0-250mm, length 800-5000mm

Nickel seamless pipe: outer diameter 12-219mm, wall thickness 0.5-2.0mm, length 1000-12000mm

Nickel hot rolled sheets

Nickel hot rolled sheet: thickness 3.0-70.0mm, width 300-2500mm, length 500-8000mm

nickel cold rolled sheets

Nickel cold rolled sheet: thickness 0.8-6.0mm, width 300-1300mm, length 500-4000mm

NICKEL COLD ROLLED STRIPS

Nickel cold rolled strip: thickness 0.05-3.0mm, width 200-1250mm

nickel flanges:

Nickel flanges: produced according to ASME 16.5, HG20592, SH3406, and other standards.

Nickel discs and rings

Nickel disc and ring: outer diameter 150-1500mm, wall thickness 15-300mm, height 20-500mm

Nickel fittings:

Nickel fittings: outer diameter 19-1210mm, wall thickness 2.0-16.0mm

Nickel fasteners:

Nickel fasteners: according to ISO,DIN ANSI ASME JIS standard.

production equipment

Baoji Pelifly Titanium Industry Co., Ltd

At present, the company has a vacuum self-consumption furnace, fast forging machine, plate tying machine, metal diagonal tying and perforating machine, milling machine, lathe, sawing machine, laser cutting machine, shearing machine, vacuum heat treatment furnace, argon arc welding machine, spectrometer, hardness tester, ultrasonic flaw detector and so on hundreds of production equipment and testing equipment. 2023 completed the production of nickel and nickel alloy materials 2,000 tonnes, customers have widely recognized our N6 nickel plates.

hydraulic pressure machine

Workers use hydraulic presses to press ingots

Fully automatic control vacuum consumable arc furnace

Vacuum Induction Melting Furnace

it can work continuously without destroying the vacuum of the melting chamber and improve the working efficiency.

rolling sheet machine

Machines for making sheets and strips.

package Nickel sheets

delivery

Bulk shipments

After passing the test, the nickel plates will be sorted according to the size and ready to be packed and shipped.

Package

Boxed and bound for shipment

Each board is marked with a good size standard quantity weight, put into the corresponding size of the wooden box, wooden box in advance of the bedding, and then bound, ready to go out of the warehouse
